PRX715

Full range, 2 channel, 15in active.

Max. SPL: regular 136dB

          propel 136dB

Freq. Range(+10dB): Main system 42.9Hz-19.5kHz

                       Monitor: 43.6Hz-19.3kHz

Freq. Response: Main system: 58.1Hz-17.2kHz

                Monitor: 60.7Hz-17.2kHz

Connectors Input: 2x balance XLR, 1/4 in input

Input Impedance: 20k Ohms (Balance)

Signal connector: Limit: the yellow LED indicates that the highest peak has been reached and the limiter is running: the green LED indicates a signal.

Power / Standby: Blue means that the system is powered on and can be connected to the audio source, red means the system is powered but only in the power saving mode, can not be connected to the audio.

Equalizer: The user can select the master system or monitor position.

Dynamic Control (Input): dbx style,  TV TM  Limiting circuit

Crossover frequency: 1.7kHz

Amplifier：

Style：CIass-D Amplifier

Power：1100W+550W

AC power input：200-240V ~50/60 Hz

Speaker:

LF drivers：1x15" (φ75mm)

HF driver：1xφ51mm (compress driver)

Dispersion: 90x50°

Directivity index(DI): 10.5dB

Directivity factor(Q): 10.4

Cabinet: 15mm plywood

Hanging/install: 1x36mm pole, 12xM10 suspension points

Transport: two back cover mold handle, twelve overall link handle.

Paint: Floating point of water - based environmental spray paint treatment,

Net: Black environmental spray, Φ6mm transparent silver fiber mesh lining

Dim(HxWxD): 735.3x448.5x547.3mm

N.W: 35kg

G.W: 39kg
