Design for outdoor touring show.Cabinet was design into two part to reduce weight.

HF consist of two pcs drivers, ensure both the sound presure, a penetrating sound,and gorgeous surper HF. Mid LF with three pcs 15" drivers, 12ohm of each, frequency response upper limit of 2kHz, easy to connect with HF.

Each cabinet carry independent crossover, can be used independently.

Feature:

patented product.

18mm fire-proof board made in Japan.

corner cover by aluminium alloy to avoid damage by collision.

universal wheel for easy moving.

SPECS

Rated Power: 1850W

Component: LF3x15" (φ100mm)/ HF2x100mm/ Surper HF1x51mm

Impedance: 4Ω

Dispersion: 90x60°

Sensitivity: 106dB

Max. SPL: 138dB

Freq. Response: 40-18.5kHz

Cabinet: 18mm fire-proof plywood

DIM(WxDxH):

MEAS(WxDxH):

N.W: 150kg

G.W: 150kg
